ES-V-104G Micro Switch with 14mm Roller Lever | Precision Industrial Sensing ⚙️🔘

The ES-V-104G Micro Switch is a high-sensitivity snap-action component engineered for precise limit detection and automated control. Featuring a 14mm roller lever, this switch translates mechanical motion into electrical signals with minimal friction, making it an essential part for high-cycle industrial applications.

Key Product Features

• Precision Snap-Action Logic: Engineered for instantaneous switching, providing a crisp electrical response the moment the roller lever is engaged.

• 14mm Roller Lever Actuator: Equipped with a smooth-action stainless steel roller that reduces wear on moving parts and allows for actuation from various angles.

• Dual-Voltage Performance: Robustly rated to handle high-capacity loads including 16A 250VAC for heavy machinery and 0.6A 125VDC / 0.3A 250VDC for specialized DC circuits.

• Triple Terminal Configuration: Features three high-conductivity spade terminals providing Normally Open (NO), Normally Closed (NC), and Common (COM) wiring options.

• Certified Industrial Build: Carries recognized CE and CCC safety certifications, ensuring compliance with global electrical standards for safety and reliability.

• Durable Thermoplastic Housing: The grey industrial-grade casing is designed for high heat resistance and mechanical stability in demanding environments.

Technical Specifications

• Model: ES-V-104G

• AC Rating: 16A 250VAC.

• DC Rating: 0.6A 125VDC / 0.3A 250VDC.

• Actuator Type: 14mm Stainless Steel Roller Lever.

• Certifications: CE, CCC.

• Application: Ideal for conveyor limit sensing, CNC machinery, safety door interlocks, and automated packaging systems.

Top 3 Customer Questions & Concerns 🙋‍♂️

⚙️ What is the advantage of a roller lever over a standard flat lever? Friction reduction. The roller allows the cam or mechanical trigger to slide across the actuator smoothly, significantly extending the mechanical life of both the switch and the part interacting with it.

🔌 How do I choose between the NO and NC terminals? It depends on your circuit's goal. Use the Normally Open (NO) terminal if you want the device to turn ON only when the lever is pressed. Use the Normally Closed (NC) terminal if you want the device to turn OFF when the lever is pressed (standard for safety limit switches).

⚠️ Can this handle high-amperage motors? Yes, it is rated for up to 16A at 250VAC, which is sufficient for many medium-sized industrial motors and heaters. For extremely high-torque motors, we recommend using this micro switch to trigger a dedicated power contactor or relay.
